Overview

VRMesh stands out as an advanced software tool designed for the processing of point clouds and meshes. Our innovative technologies are tailored to deliver powerful and user-friendly solutions specifically crafted for the Architecture, Engineering, and Construction (AEC) industry. The VRMesh family comprises four distinct packages, each catering to the diverse needs of our varied customer base. (Download product brochure )

VRMesh Studio:
It encompasses all features within VRMesh, spanning point cloud classification, feature extraction, point cloud meshing, and polygon modeling. This comprehensive workflow enhances work efficiency and significantly boosts productivity, especially in the fields of architecture, engineering, and construction.

VRMesh Site:
It not only converts point clouds into accurate meshes, but also possesses the capability to directly fit a polygonal surface to point clouds and easily edit the polygonal surface on point clouds. This streamlines digital construction processes efficiently.

VRMesh Reverse:
It facilitates the seamless and accurate conversion of large point clouds into meshes, while providing a comprehensive toolset for tasks such as point cloud cleanup, mesh repair, and mesh editing.

VRMesh Survey:
It classifies point clouds generated from LiDAR and UAV images, facilitating the automatic extraction of building footprints, powerlines, poles, tree crowns, railways, curbs, and breaklines with remarkable precision.

VRMesh Modules:

Point Cloud Classification

Classify vegetation, building roofs, and ground points in LiDAR data or from UAV images

Work well under extreme variations in terrain



Feature Extraction

Extract building footprints, powerlines, poles, tree crowns, and curbs from point clouds automatically

Extract a line along a ridge, railway, road markings

Point Cloud to Mesh

Create an accurate mesh in great detail

Create a mesh for visualizing large-volume scans



Construction Module

Detect lines, pipes, walls, floor/ceiling in one click

Fit curbs, edges, profiles to point clouds

Mesh Repair & Editing

Seam gaps, stitch boundaries, remove inside parts to create a clean surface mesh

Decimation, smooth, offset, refinement, Boolean, etc.



Polygon Modeling

Move, extrude, optimize polygons

Fit polygons to point clouds directly

Digital Clay

Provide brush tools for sculpturing surface, such as pulling, pushing, flattening, smoothing, embossing, etc.

Mark

Classify surface mesh, Texture mapping



Water Catchment Analysis

Calculate the direction water will flow, find catchment areas and extract catchment boundaries

Measure the length/slope of flow path and the area of catchment

Registration

Align a CAD model to point clouds

Global registration working on unstructured points



LiDAR Strip Adjustment

Separate overlapping LiDAR strips

Inspection & Measurement

Deliver accurate inspections between digital reference models

Measure deviation, slop, volume, area, distance, etc.



Plugin for Autodesk Civil 3D

Send data between VRMesh and Autodesk Civil 3D

3D Mouse

Support 3DConnexion SpaceMouse


File Formats:

Import: e57, las, laz, ptx, pts, asc, stl, obj, dxf, shp, ply, zfs, rdbx, wrl, vtk, csv, rcp, step, iges, ifc, landxml

Export: las, laz, pts, asc, iges, stl, obj, dxf, fbx, shp, grid, wrl, ply, vtk, csv, x3d, pdf, rcp, landxml, nwc, gltf

Data Handling:

No limit to the size of point clouds

Support batch processing of multiple files
